How Towing Weight Distribution Systems Work

By:Jessika Toothman|
Towing weight distribution systems like this one can make towing large loads a safer experience.
Towing weight distribution systems like this one can make towing large loads a safer experience.
Jacquelyn Childress/etrailer.com

Most people who've driven a trailer have experienced at least a few heart-pounding moments when their trailers started to sway and they worried they might lose control of the vehicles. One way to help ensure disaster won't strike, especially if you're pulling a very large load, is to use a weight distribution system.

To understand how a weight distribution system works, we need to familiarize ourselves with two terms. The first one isgross trailer weight(orGTW), which, as you can probably guess, describes the total weight of the trailer, including cargo, fuel and anything else you've got in there. The second term istongue weight. Tongue weight is the portion of the load (generally between about 10 and 15 percent of thegross trailer weight)that's far enough forward in the trailer that it presses down on the hitch. Tongue weight (orTW) also includes any weight that's behind the rear axle of the towing vehicle. So if you plan on loading up the trunk, you'll need to factor that in.

Advertisement

Having too much tongue weight in relation to gross trailer weight can cause the hitch of the trailer -- and the rear axle of the tow vehicle -- todive, meaning the front of the trailer will head toward the ground, bringing the front of the towing vehicle off of the ground. Obviously, if your tow vehicle dives too far, such as in situations when you need tobrakequickly, you'll loose braking traction and steering control of the wheels on the front axle, which can be very dangerous. The opposite is also true of too little relative tongue weight. In those situations, a trailer will be more prone tosway, and it can swing back and forth out of control. Because of these two factors, you can see why finding the delicate balance between tongue weight and gross trailer weight is so vital.

Weight distribution hitches can help prevent those dangerous conditions and improve a vehicle's ability toturn, brake and steer, especially in the case of large loads, which can be hard to maneuver in a safe and controlled manner. On the next page, we'll take a closer look at how this is possible.

Advertisement

Purpose of Towing Weight Distribution Systems

The difference between using a weight distribution system and going without is clearly illustrated here.
The difference between using a weight distribution system and going without is clearly illustrated here.
etrailer.com

We learned on the last page aboutgross trailer weightand tongue weight and why they're such big factors intowing a trailer. Keep in mind, too, the more weight you add to the equation, the more the situation is exacerbated. While a weight distribution system can't increase the total amount of weight a tow vehicle can haul beyond its maximum capacity, it can improve handling by distributing some of the weight off the tongue and onto the other axles -- thereby safely getting you closer to that maximum mark.

To understand this, keep in mind what we read on the last page concerning too much or too little tongue weight. With a weight carrying hitch -- one lacking a weight distribution system -- there needs to be a delicate balance struck between how much weight is on the tongue, or your towing excursion could end in disaster.

Advertisement

You still need to carefully keep the same ratios of tongue weight andgross trailer weightin mind with a weight distribution hitch, but when you have a heavier load you have to consider how much moretongue weightthat actually entails. A weight distribution system is important because it eases the situation by spreading some of that increased tongue weight off the rear axle of the tow vehicle and onto the front axle, as well as the axle (or axles) of the trailer. With that leverage, everything balances out and driving performance increases dramatically. Also, don't forget the tow vehicle's axles each have a gross axle weight rating -- adjusting the weight distribution system can help distribute the weight appropriately.

如果你想拖一个较小的负荷,一般you can get away with a weight carrying hitch. As the gross trailer weight creeps up on the scales, a weight distribution hitch might start to look a lot more attractive. Usually if your trailer weighs in at more than 50 percent of the towing vehicle's weight, you'll need one of these hitches. Plus, once you reach certain gross trailer weights, a weight distribution system is required by law anyway. So how do you know which one to get? On the next page, we'll delve a little deeper into what you should consider when picking out a weight distribution system.

Advertisement

Choosing Towing Weight Distribution Systems

A towing weight distribution system with added sway control.
A towing weight distribution system with added sway control.
Jacquelyn Childress/etrailer.com

The most important thing to keep in mind when picking out a weight distribution system is the weight of the load you'll be towing. Weight distribution systems are rated in two ways: thegross trailer weightthey can haul, and the tongue weight they can distribute. You want to make sure both of those ratings are above the amount you're looking to tow -- but not too far above it.

例如,如果重量分配系统a 1,000 pound (454 kilogram) tongue weight capacity but the trailer is loaded with only 300 pounds (136 kilograms) of tongue weight with 50 pounds (23 kilograms) of cargo in the trunk of the towing vehicle, you're about 650 pounds (295 kilograms) under the rating. That can make the distribution unpredictable and dangerous. On the other hand, if the system is rated to 1,000 pounds (454 kilograms) of tongue weight but you're attempting to distribute 1,500 pounds (680 kilograms) of tongue weight, the system won't be able to distribute the weight effectively and you'll also have some serious problems. Keep that infamous rule from "The Price Is Right" in mind when choosing a weight distribution system -- you want to bid the closest without going over.

Advertisement

A second choice you'll have to make during the selection process is which type of spring bars you want in the system. There are two common basic styles: round or trunnion. Round bars usually offer a little more clearance space for hooking up the trailer, but trunnion bars can increase the system's weight rating. The advantages presented by either round or trunnion bars vary from setup to setup, so it's good to consult with someone who has experience while you're trying to decide.

Another factor to consider when purchasing a weight distribution system is whether you want additional features like sway control. Generally, the systems are naturally less inclined to sway so you can probably hold off on that purchase at first. If you're still experiencing sway (and provided you didn't do a really bad job packing or are driving too fast), then you might want to look into adding a sway control system too. Some systems are two-in-one, with weight distribution systems and sway control systems combined.

On the next page, we'll look at how weight distribution systems are installed and the nitty-gritty on how they operate.

Advertisement

Installing Towing Weight Distribution Systems

A towing weight distribution system with each portion numbered.
A towing weight distribution system with each portion numbered.
Jacquelyn Childress/etrailer.com

Most trailer hitches feature a 2-inch receiver and the weight distribution system can be inserted directly into that. The first part you'll install is called a shank. These usually plug into the receiver and can be turned in an upward or downward direction, due to the fact that when both vehicles are level, one is often lower or higher than the other. A head assembly is mounted onto the shank, and it provides both the platform for the hitch ball and the spring bars. At this point, the trailer can be re-hitched to the towing vehicle.

Once the vehicles are back together, we can continue installing the weight distribution system. In most systems, the setup basically works like this. Spring bars (remember either round bars or trunnion bars) run from the head assembly to a pair of chains. These chains hang down below the trailer from a set of brackets and attach to them in a way that creates tension along the spring bars. As the tongue weight pushes the bars down, the chains pull the bars up. In order to straighten out to their natural positions, the spring bars push up on the head assembly, distributing the weight among the axles.

Advertisement

The next step in the process is usually to attach the chains to the spring bars and insert the bars into the head assembly. Then the brackets are mounted on the trailer and the chains are attached to those, often with a lift lock. The brackets should be lined up with the ends of the bars, and you generally want at least five chain links showing.

There are two main elements to keep in mind during the installation process. The first is the change in the height of the wheel well rims of the two vehicles. You'll want to measure them before, during and after installation to make sure the weight distribution system is spreading the weight evenly and appropriately. The second aspect is the angle of the bars -- they should run parallel to the tongue of the trailer or downwards towards the ground, and often the head assembly can be tilted to accommodate this or the amount of chain links can be adjusted.

Some systems (especially those that also offer enhanced sway control) may use slight variations, such as a pair of L-shaped brackets in place of the chains, but the systems work in similar ways. Just remember that it's a very good idea to get a professional to help you determine what weight distribution system will work best for you, and to follow the instructions carefully while you're installing it. Once you're ready to ride, get lots more great transportation links on the next page.

Advertisement

Originally Published: Oct 8, 2008

Weight Distribution Hitch FAQ

How does a weight distributing hitch work?
A weight distribution hitch distributes the total weight of the trailer, including cargo, fuel and anything else in the truck, to the vehicle’s and trailer’s axles, relieving the vehicle’s bumper for increased safety and maneuverability.
What is the purpose of a weight distribution hitch?
The primary purpose of a weight distribution hitch is to prevent dangerous conditions like the trailer swinging or losing the ability to brake, steer, turn and maintain control of the trailer.
How do you set up a weight distributing hitch?
First, you install a shank that plugs into the receiver. A head assembly is then mounted onto the shank, which provides the platform for the hitch ball and spring bars. The next step is to attach the chains to the spring bars and insert the bars into the head assembly. Then, the brackets are mounted on the trailer and the chains are attached to them usually with a lift lock. Make sure that the brackets are lined up with the ends of the bars.
Can I tow more with a weight distribution hitch?
No, it doesn’t increase your vehicle towing capacity. As a standard rule, if your trailer weighs more than half of your tow vehicle, you have to use a weight-distribution hitch.
Can you back up with a weight distribution hitch?
While you can backup with a weight distribution hitch, it is important to be careful when doing so. Before backing up, make sure that you have disengaged the sway control.
